20 SERIES GRAPHIC EQUALIZERS
dbx 2031 Graphic Equalizer
Block Diagram
12/20/96
.....
VCA VCA
40Hz
GRAPHIC
EQ
PeakPlus TM
Limiter
Detector/
Timing
TYPE III NR
Detector/
Timing
PeakPlus
TM
Threshold
20Hz 20kHz
EQ
Bypass
±6dB ±15dB
Range
CLIP
Input
Gain
Input
Output
Level
Gain
Reduction
RF Filter
RF
Filter
Output
