WEAPON EMPLOYMENT

№

Element

Function

8. Elevation Scale Allows to determine antenna elevation tilt angle.

9. FAIL Light

Illumination indicates radar failure.

10. LK ON Light Illuminates when radar is locked on or range-tracking

target.

11. ARL Mark Indicates armament reference line.

12. Excess G Light Indicates excess-g condition for successful missile

guidance.

13. Elevation Cursor Indicates antenna elevation tilt angle.

14. Azimuth Grid Allows to determine the azimuth of target.

15. Dogfight/Resume Search Switch Initiates search phase and breaks lock if radar was

locked on.

16. Radar Mode Selector Selects radar operation mode.

17. Acquisition (ACQ) Button Press (Momentary) – locks on to target or breaks

lock-on.
