COCKPIT
1.
Flap Indicator on the instrument panel provides visual indications
of flap position when the Flap Thumb Switch on the Right Engine
Throttle is used.
2.
Airspeed/Mach Indicator. The Airspeed/Mach Indicator displays
airspeed in knots from 80 to 850 and in Mach number from 0.5 to
2.2.
The indicator includes:
• Maximum allowable indicated airspeed pointer (red);
• Maximum allowable landing gear extension airspeed index
(yellow).
3.
Attitude Indicator shows roll and pitch parameters relative to the
horizon, providing an indication of the aircraft's orientation. When
maneuvering at high angles of attack, the vertical gyro may tilt. In
this case, the OFF flag will appear, and the instrument readings
will be incorrect.
4.
Pitch Trim Indicator.
The instrument displays trim position.
For players’ convenience, there is a mark corresponding to 10
increments of nose-up trim on aircraft controls position indicator
R.Ctrl + Enter .
5.
Clock shows the current time.
6.
Engine Tachometers indicate the current engine RPM as a
percentage. Smaller scale is graduated in increments of 1%, larger
scale is graduated in increments of 2%.
Red indices show the minimum idle RPM and maximum
permissible RPM at Military (MIL) or Afterburner (AB) Power.
The continuous RPM range is indicated in green.
