DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-3
2.1 Cabinetry Components, Single Fryers (cont.)
ITEM PART # COMPONENT
* 210-3419 Top Cap (Front Canopy)- SM50GDD
* 210-2821 Top Cap (Front Canopy)- SM60G, SR62G
* 210-2811 Top Cap (Front Canopy)- SM80G
19 12-0366-2 Flue Cap- SR38G obsolete
* 823-4175 Flue Cap- SR42G, SR52G (After Feb. 2003 ) obsolete Use 230-0031
* 823-4437 Flue Cap- SR62G
* 823-3467 Flue Cap- SM35G, SM40G (SR42G, SR52G Prior To Feb. 2003) obsolete
* 823-3700 Flue Cap- SM20G
* 823-3702 Flue Cap- SM220G
* 823-3521 Flue Cap- SM50G
* 823-3575 Flue Cap- SM50GDD
* 823-3635 Flue Cap- SM60G
* 823-3512 Flue Cap- SM80G
20 12-0401 Back, Upper Cabinet- SR38G obsolete
* 200-1123 Back, Upper Cabinet- SR42G, SR52G, SM35G, SM50G
* 200-1377 Back, One-Piece Cabinet- SM35G, SM50G
* 200-1674 Back, Upper Cabinet- SM50G (SUFF), SM220G
* 200-1213 Back, Upper Cabinet- SM60G / SR62G
* 200-2683 Back, Upper Cabinet- SM80G
21 12-0402 Back, Lower Cabinet- SR38G obsolete
* 200-1126 Back, Lower Cabinet- SM35G, SM50G, SM50GDD
* 200-1327 Back, Lower Cabinet- SM60G
* 210-2684 Back, Lower Cabinet- SM80G
Door Assembly Components
22 200-3807 Panel, Inner Door- SM20G
* 200-1379 Panel, Inner Door- SM220G, SM35G, SM40G, SM50G
* 200-1185 Panel, Inner Door- SM60G
* 200-2688 Panel, Inner Door- SM80G
23 12-0308-2 Panel, Door- SR38G obsolete
* 210-4770 Panel, Door- SR42G, SR52G (Assembly 106-3150SP)
* 210-5642 Panel, Door- SR62G (Assembly 106-3444SP)
* 106-4728 Door Assembly, Right with Liner- SM50
* 210-3805 Panel, Outer Door- SM20G (Assembly 106-2482SP)
* 210-2869 Panel, Outer Door- SM220G, SM35G, SM40G, SM50G (Assembly 106-1754SP)
* 210-1424 Panel, Outer Door- SM60G
* 210-1151 Panel, Outer Door- SM80G (Assembly 106-1698SP)
24 200-1301 Pin, Door- All Millivolt Fryers (Use 826-1343 for Springs qty. 10)
* 106-1698SP Pin, Door Assembly- All Millivolt Fryers (short)
25 809-0413 Spacer, Nylon- All Millivolt Fryers
26 200-1307 Hinge, Door- Lower- All SR Series Fryers
* 200-1675 Hinge, Door- Lower- All SM Series Fryers
27 810-0180 Handle, Door- Chrome- All SM Series Fryers
* 809-0918 Screw, #10-24 x ½" (Use With 810-2105)
* 809-0191 Washer, Lock ¼" (Use With 810-2105)
* 810-1422 Handle, Wireform- Door- SR42G, SR52G (Use 810-2030 before Jan. 03)
* 826-1379 Screw, #10 x ½" Round Phillips (Qty: 10) (Use With 810-1422)
28 810-0066 Catch, Magnetic Door- All Millivolt Fryers
* 823-3225 Splash Guard 42’s & 50’s (Use 823-4767 for 60’s & 80’s)
* 200-3663 Striker Plate all models except SR42
* 210-2897 Striker Plate SR42
* 803-0197 Fryers Friend Cleanout Tool
* Not Illustrated
