DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-27
2.8 Under Fryer Filter (UFF) Components
2.8.1 SM50 and SM60 Series Fryers (Except IHOP)
1
2
3
4
5
6
7
8
9
10
11
12
ITEM PART # COMPONENT
1 823-3576 Filter Pan- UFF 50
* 106-2115SP Filter Pan Assembly- UFF 50
* 106-0749SP Filter Pan Assembly- UFF 60
2 809-0805 Screw, ¼"-20 x ½"
3 809-0428 Bolt, ¼"-20 x ½" Steel
4 809-0820 Nut, Oval Locking- ¼"-20
5 823-4794 Insert, Caster
6 810-2805 Caster, 2"-Swivel
7 823-3574 Support Grid (Bottom Pan Screen)- UFF 50
* 823-3365 Support Grid (Bottom Pan Screen)- UFF 60
8 803-0289 Filter Paper, 22" x 34"- UFF 50/60 (100 Sheets)
9 823-3573 Hold-down Ring, Weighted- UFF 50
* 823-3361 Hold-down Ring, Weighted- UFF 60
10 823-4320 Crumb Basket, UFF 50/60
11 106-0752SP Lid Assembly, Front- UFF 50/60
12 106-1755SP Lid Assembly, Rear- UFF 50
* 106-0753SP Lid Assembly, Rear- UFF 60
* Not Illustrated
