DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-28
2.8.2 SM50 Series Fryers, IHOP UFF 50 with Filter Leaf
1
2
3 4
5
6
7
8
10
11
9
ITEM PART # COMPONENT
106-2109SP Filter Pan Assembly- UFF 50 IHOP (includes items 1-5)
1 823-3703 Filter Pan- UFF 50 IHOP
2 810-2805 Caster, 2"-Swivel
3 809-0823
Nut, Nylock ¼
"-20
4 813-0336 Plug, Pipe- S/S- ½" NPT
5 813-0679 Plug, ⅛" S/S Square Head
6 810-2350 Leaf, Filter- UFF 50 IHOP
7 810-2351 Handle, Filter Leaf Tee Fitting
8 823-3872 Crumb Basket, UFF 50 IHOP
9 106-0752SP Lid Assembly, Front- UFF 50
10 106-0753SP Lid Assembly, Rear- UFF 60
11 810-0180 Handle, Filter Lid- Front & Back
* 809-0191 Washer, ¼" Lock- Filter Lid Handle
* 809-0918 Screw, #10-24 x ½"- Filter Lid Handle
* Not Illustrated
