DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-29
2.8.3 SM80 Series Fryers
1
2
3
4
5
6
7
8
12
9
10
11
ITEM PART # COMPONENT
1 106-1584SP Filter Pan, UFF 80
2 823-3365 Support Grid (Bottom Pan Screen) (Use 823-4938 for Chili’s)
3 803-0303 Filter Paper, 26" x 34" (100 Sheets)
4 823-3439 Hold-down Ring, Weighted
5 823-3443 Crumb Basket
6 106-1587SP Filter Pan Cover, Front
7 106-1588SP Filter Pan Cover, Back
8 809-0428 Bolt, ¼"-20 x ½" Steel
9 823-4794 Insert, Caster
10 809-0820 Nut, Oval Locking- ¼" -20
11 809-0805 Screw, ¼"-20 x ½"
12 810-2805 Caster, 2"
