Dean Super Runner Series - SM60 and SM80 Series Fryers

DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-31
2.9.2 SM60 and SM80 Series Fryers
1
2
3
4
5
6
7
8
12
9
10
11
ITEM PART # COMPONENT
1 823-3774 Filter Pan, SUFF 60 (Use 106-2228SP for Assembly)
* 823-3821 Filter Pan, SUFF 80 (Use 106-2381SP for Assembly)
* 813-0684 Plug, Hex Socket, ⅜" NPT
* 813-0679 Plug, ⅛" S/S Square Head (Female Disconnect)
2 823-3768 Support Grid (Bottom Pan Screen) SUFF 60/80
3 803-0289 Paper, Filter- 22" x 34" - SUFF 60/80
4 823-3768 Hold-down Ring, Weighted- SUFF 60
* 823-3849 Hold-down Ring, Weighted- SUFF 80
5 823-3736 Crumb Basket- SUFF 60/80
6 823-3766 Filter Pan Cover, Front- SUFF 60
* 823-3739 Filter Pan Cover, Front- SUFF 80
7 823-3767 Filter Pan Cover, Back- SUFF 60
* 823-3741 Filter Pan Cover, Back- SUFF 80
8 809-0428 Bolt, ¼" -20 x ½" Steel
9 823-4794 Insert, Caster
10 809-0820 Nut, Oval Locking- ¼"-20
11 809-0805 Screw, ¼" -20 x ½"
12 810-2805 Caster, 2"
* Not Illustrated
