DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-26
2.7.2 Oil Return and Oil Flush Components; Fryers with 3” Drains (cont.)
ITEM PART # COMPONENT
106-4006
Microswitch Bracket Assembly, Oil Return
1 901-2772 Handle, RF Left
2 900-2935 Retainer, Nut
3 816-0220 Insulation, RF Switch
4 810-0278 Ball Valve, ½” Oil Return
5 826-1366 Nut, 4-40 Keps hex w/ External Teeth (Pkg. of 25)
6 807-2103 Microswitch, Straight Lever (CE)
7 200-6806 Cover, Safety Switch
8 106-3962 Bracket Assembly, RF Switch
106-1225
Oil Suction Assembly
9 813-0062 Elbow, 90º BM
10 813-0173 Union, ½” NPT 150# BM
11 813-0654 Nipple, TBE ½” NPT x 4” BM
12 813-0674 Nipple, TBE ½” NPT x 7.25” BM
13 200-1230 Bracket, Front male Manifold
106-0774
Suction Manifold Assembly
14 810-0697 Disconnect, Male Suction Tube
15 813-0608 Coupling, ½” NPT BM Full
16 823-3188 Suction Manifold
106-0858
Oil Suction Start Fitting
17 813-0022 Nipple, ½” NPT Close
18 813-0463 Plug, ½” Counter Sink
19 813-0003 Tee, ½” NPT BM
* 210-8790 Bracket, Oil Return/ Flush Retainer
* 200-8929 Handle, Oil Return
* 200-9850 Handle, Oil Return (Application Series “DF” Fryers)
* 816-0548 Cap, Oil Return Handle, Yellow
* 816-0549 Cap, Oil Return Handle, Blue
20 810-2097 Motor/Pump Combo, 120-230V
* Not Illustrated
