DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-7
2.3 Component Box Components and Related Components (CE and
Domestic- cont.)
ITEM PART # COMPONENT
1 826-2013 Thermostat, Sunne (Use 807-1692 for CE)
* 810-2047 Spring, Spacer- Thermostat Capillary Bulb
* 210-1302 Clamp, Thermostat/High Limit Capillary Bulb (Use 210-1433 for 2 hole)
* 200-1320 Mounting Bracket, Thermostat & High-Limit
2 810-2035 Knob, Thermostat (Use 816-0139 for CE)
3 200-1618 Box, Thermostat- Single
4 200-3217 Cover, Thermostat Box- Single
5 200-3277 Box, Thermostat- Dual (Used in 20/50 Combination Systems)
6 200-3906 Cover, Thermostat Box- Dual (Used in 20/50 Combination Systems)
7 810-2033 Thermopile (Use 807-3565 for CE)
8 810-1152 Thermocouple (CE ONLY) (Use 812-1284 for Assembly)
9 106-1768SP ECO Connector (Honeywell Valves Only- CE ONLY)
* 106-1879 ECO Connector (Robertshaw Valves Only- CE ONLY)
10 200-5479 Bracket, Pilot Thermocouple
11 810-2401 Bracket, Thermopile
12 810-1001 Piezo Ignitor (Trigger) (Wire Lead-807-3650) (Assembly-44970SP)
* 200-1868 Piezo Bracket
* 807-3540 Electrode, Piezo CE (Use 812-1532 for modified Electrode)
13 807-1999 Transformer, Dual Voltage CE- Filtration System (CE ONLY)
* 807-0800 Transformer, 120/24 VAC- Filtration System
14 807-3580 Switch, Rocker- Manual Filter Power
15 210-2786 Guard, Switch (Optional- For Item 10)
16 807-3516 High-Limit Thermostat- Automatic Reset 435° F SM20/35,SR40/42
* 807-3560 High-Limit Thermostat- Manual Reset 410° F (CE)
* 807-3680 High-Limit Thermostat- Manual Reset 450° F
* 810-2046 Spring, Spacer- High Limit Capillary Bulb
17 807-1321 Fuse Holder, Buss
* 2747 Fuse Holder, Slot-head—Safety (CE ONLY)
* 807-3592 Fuse 2A Slow-Blow (230V Systems)
* 807-3750 Fuse 5A (120V Systems)
* Not Illustrated
