DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-14
2.4.3 SR62, SM60G and SM80G Systems (cont.)
ITEM PART # COMPONENT
1 823-3506SP Frypot- M/S- SM80G (After 10/99) obsolete use 823-3494SP
* 823-3494SP Frypot- S/S- SM80G (After 10/99) 1¼” (Use 823-3396SP for 1 ½”)
* 20004-3SK Frypot- M/S- SM80G (Prior To 10/99) obsolete use 826-1891
* 826-1891 Frypot- S/S- SM80G (Prior To 10/99)
* 826-1819 Frypot- M/S- SM60G obsolete use 826-1802
* 826-1802 Frypot- S/S- SM60G, SR62G (Use 823-3511SP for SM160G)
2 823-3404 Diffuser, Burner Tube- SM80G
* 210-5215 Diffuser, Burner Tube- SM60G, SR62G
3 810-2150 Burner, Right- SM60G, SM80G, SR62G
4 810-2149 Burner, Center- SM60G, SM80G, SR62G
5 810-2151 Burner, Left- SM60G, SM80G, SR62G
* 200-2734 Bracket, Burner Mounting- SM80G
* 200-2738 Bracket, Burner Mounting- SM60G, SR62G
* 200-2707 Shield, Burner Heat- SM80G
* 200-2746 Shield, Burner Heat- SM60G, SR62G
6 200-1314 Bracket, Manifold Mounting- SM80G
* 200-1615 Bracket, Manifold Mounting- SM60G, SR62G
7 809-0428 Bolt, ¼”-20 x ½" Hex Head
8 809-0823 Nut, Nylock- ¼”-20
9 810-2138 Valve, Trailing Pilot- SM60G, SM80G, SR62G adjustment valve
10 813-0642 Tee, ⅛” NPT
11 813-0705 Plug, Brass- ⅛” Square Head
12 813-0643 Nipple, ⅛" NPT x Close BM
13
Orifice- Domestic/International
* 810-2062 Orifice, Natural- #38 (2.58 mm)- SM80G
* 810-2048 Orifice, Natural- #39 (2.53 mm)- SM60G, SR62G
* 810-2063 Orifice, LP- #52 (1.61 mm)- SM80G, SR62G (Australia)
* 810-2059 Orifice, LP- #53 (1.51 mm)- SM60G, SR62G
*
Orifice- CE Only
* 810-2060 Orifice, G20-G25- (2.40 mm)- All Millivolt Fryers in This Section
* 810-2059 Orifice, G31- (1.51 mm)- All Millivolt Fryers in This Section
14 823-3617 Manifold, Gas- SM60G, SM80G, SR62G
15 810-2036 Valve, Gas- Natural, Honeywell- Domestic/Intl ½” in x ¾” out
* 807-2122 Valve, Gas- Natural, Honeywell- CE Only
* 807-3648 Valve, Gas- Natural and MFG, Honeywell ¾” in x ¾” out (Export)
* 807-3645 Valve, Gas- Natural, Robertshaw MV ½” in x ¾” out
* 807-3549 Valve, Gas- LP, Honeywell- Domestic/Intl
* 807-2121 Valve, Gas- LP, Honeywell- CE Only
* 810-2399 Valve, Gas- LP, Robertshaw MV
16 813-0174 Union- ¾" NPT BM
17 813-0635 Nipple, ¾" NPT x 2-½" BM
18 813-0066 Elbow- ¾" NPT 90° BM
19 813-0743 Nipple, ¾" NPT x 3-½" BM
20 813-0165 Elbow, Street- ½" NPT 90° BM
21 813-0670 Nipple, ½" NPT x 19" BM (Measure To Confirm Length)
* 813-0585 Nipple, ½" NPT x 20-½" BM (Measure To Confirm Length)
* 813-0737 Nipple, ½" NPT x 21" BM (Measure To Confirm Length)
* Not Illustrated
