DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-19
2.5.2 3” Oil Drain Manifold, Drain Flush & Drain Valve Components (cont.)
ITEM PART # COMPONENT
1 823-4712 Tube, 3” Oval Dump
2 823-4681 Tube, 3” Right Drain (closed end)
3 823-4682 Tube, 3” Center Drain (open ends)
4 823-4844 Tube, 3” Left Drain (closed end)
5 823-5188 Tube, 3” Right Filter (open ends)
6 200-6603 Tube, 3” Joiner (11.5”)
7 200-9365 Tube, 3” Joiner (8.63”)
8 809-0969 Clamp, T-bolt
9 816-0625 Boot/Sleeve
106-1726
Flush Oil Drain Line
10 810-1669 Adapter, Female ⅝” O.D. x ½” long
11 810-1668 Adapter, Male ⅝” O.D. x ½” long
12 810-1056 Flexline, ⅝” O.D. x 52.5” long
106-3976
Drain Valve Assembly, 1½” Without Microswitch
106-3977
Drain Valve Assembly, 1½” With Microswitch
13 810-2783 Drain Valve, 1½” Full Port with O-ring
14 823-4734 Handle, Drain Valve Rotating
15 807-2104 Microswitch, CE Micro-roller Lever
16 106-1401 Microswitch Bracket Assembly
17 200-4402 Guard, Drain Microswitch
18 816-0220 Insulation, RF Switch
19 816-0547 Cap, Red Vinyl for Handle
20 200-6116 Strap, 1½” (holds tube to valve via the stud)
21 200-1617 Washer, Drain Microswitch
22 200-1257 Retainer, Drain Valve
23 826-1366 Nut, 4-40 Keps Hex w/ External Teeth (Pkg. of 25)
* 816-0630 Cap, Vinyl (one per clamp, covers T-bolt threads)
* Not Illustrated
To Next Page
