Deco Chef DGUTICM01 - Specification; Dimension;Connection; Rating

4
SPECIFICATIONS
DIMENSIONS/CONNECTIONS
Rating
MODEL
DGUTICM01
POWER SUPPLY VOLTAGE
1Phase, 110-120/60Hz
CLAIMATE CLASS
10-40℃
ELECTRICAL PROTECTION CLASS
I
ICE MAKING RATING (Amps)
2.6Amp
ICE HARVEST RATING (Amps)
2.7Amp
ICE MAKING CAPACITY (KG/24H)
36kg/24Hour
*
REFRIGERANT CHARGE
R290 2.83Oz / 80g
NET WEIGHT (lbs)
62 lbs
VESICANT
C
5
H
10
UNIT DIMENSIONS (W X D X H) (mm)
15x20.3x33.5
MAX ICE STORAGE CAPACITY (lbs)
24lbs
ACCESSORIES
SHOVEL, INSTALLATION KITS，HANDLE
CONNECTION
POWER CORD --- 18AWG
WATER SUPPLY----6.35mm diameter
DRAIN --- Φ16 SYLPHON BELLOWSS(REAR)
RUNNING CONDITIONS
ROOM TEMP 50-110 Fahrenheit
WATER SUPPLY TEMP 41-95 Fahrenheit
WATER SUPPLY PRESSURE 0.04-0.6 MPa
NOTE *: TESTED AT 70 Fahrenheit ROOM TEMPERATURE AND 50 Fahrenheit WATER
TEMPERATURE.
850
[33.5]
380
[15.0]
820
[32.3]
516
[20.3]
47
[1.9]
550
[21.7]
426
[16.8]
159
[6.3]
