A. Slide the exhaust hose assembly from the outer air outlet to the right
B. The assembly is completed un the convex point of the inner joint and the concave point of the air outlet are stuck.
STEP 4 - INSTALL WINDOW PANELS
Depending on the size of your window opening, use the main panel and one or both of the extension panels.
A. Open the window and place the main window panel into the window.
NOTE: The window assembly is designed to accommodate either a veal slide or horizonta
l slide window.
Verl Slide Window Horizontal Slide Window
B. Take out the buery nut from the user manual’s bag, and disassemble the screws in the following direons.
C. Lock the buery nut on panel A, and do not lock the buery nut htly, keeping the spacing of 2.5mm.
D. Connect with panel B, adjust the panel(s) to the width or height of the window as shown.
