E. Fasten the buery nut to the window slide set.
STEP 5 - COMPLETE INSTALLATION
Close the window as far as the window slide set, so this covers the window opening completely. Place the device at least 50
cm away from walls and other objects.
NOTE:
Some window installans may require the extension panels to be trimmed.
Slide the adapter downwards and assure adapter installed in good poson.
Assure the slant panel direon to match seal-plate direcon.
Exhaust hose cannot be bent or w
ithexure higher than 45°, in order to keep good venaon of exhaust hose.
Electrical Shock Hazard
Do not remove the ground prong from the power cord plug.
Do not use an adapter.
Do not use an extension cord.
Failure to do so can result in death,re or electrical shock.
!
WARNING
