User_Manual-PILATUS-V1_2.doc 20/57
Command or Macro Description
path for images. The imagepath command also sets
the autoname to the new path.
grafpath path
Display or change the default path for graphs. The
keyword 'grafpath' can be used in expressions as
[grafpath]
exp filename
Make an exposure. If filename is not given, TVX uses
the next automatic filename. The files created are
saved in the directory specified in imagepath.
expose exposure time
(in seconds)
expose 1: makes an image with an exposure time of 1
sec.
shortest exposure time: > 1 us, 0.000’001.
Shows the exposed image immediately on completion.
Exposem
exposure time
continuous camera mode without saving images.
Takes images until any key is pressed. The last image
is stored in temp.tif
disp filename
Display an image. Opens up to 3 windows for
successive invocations.
disp1 filename
Displays an image reusing the last window. Useful in
loops.
graf fn1[fn2[ fn3]]
Graph up to 3 graphs in a window
show variable -or-
show string
Shows the content of a variable or a string
define DEFINE name="instruction1; instruction2;....."
Defines user symbol name and value.
E.g. define tpict="zpict; move imt=im3" defines symbol
tpict as a comination of ‘zpict’, and the built-in move
instruction.
CaptureIM filename
Capture the default image to filename
captures a displayed image (and its zoom) as a .ppm
(portable pixmap) file, including coloration and
contrast adjustments.
CaptureGR filename
Capture the default graph to filename
Captures a displayed graph (and its zoom) as a .ppm
(portable pixmap) file.
connect [ip_address]
Connect the socket connection from TVX to the
Camserver at [ip_address]
disconnect Disconnect the socket connection from TVX to
