EcoSense
Video
VID1 to VID4/VID8/VID16 75Ω BNC composite video inputs 1V pk-pk (with loop
through available)
MON A 75Ω BNC composite monitor output, 1V pk-pk
MON B Spot Monitor output
S Video S Video Connection
VGA VGA Monitor output
Audio
Audio IN 2x RCA (phono) socket, 8KHz/16KHz/22KHz sampling 75Ω input
impedance, 1V pk-pk
Audio OUT 2x RCA (phono) socket, line level <100Ω output impedance,1V
pk-pk amplication required
Data
SERIAL 1 RS-232 (3 wire)
SERIAL 2 RS-485 (2 wire)
USB 2x USB2.0 connectors
NET RJ45 Ethernet network connector, 10/100 Mb/s Ethernet Network
KBD RJ12 connector for use with KBC01 or KBC02 Keyboards
Note: The KBD connection is not available on the 4 channel unit.
Alarms and relays
ALARMS IN 25 way (female) D Type 24V 200mA
17 General Alarm Inputs
Range of Alarm states are
i. 0 – 800R = Short circuit
ii. 800R – 2K = closed contact
iii. 2k – 12k = open contact
iv. > 12K = open circuit.
Note: 5 alarm inputs supported on 4 channel unit.
RELAYS Via 25 way (female) D Type rated at 24V 200mA
2 onboard light duty relay output (500mA@12V-48V Max)
Note: 1 relay output supported on 4 channel unit.
Power
POWER input for 12v DC external power unit (supplied).
