4 Technical specifications
4.1 Technical specifications
Dimensions
80 x 90 x 32,5 (l x b x h) mm
Power supply
Service tool OpenTherm OpenTherm
Electrical connection
Service tool OpenTherm OpenTherm communication. Low-voltage connection
Ambient conditions
Storage conditions Temperature: -25℃ +60℃
Relative humidity 5% - 90% no condensation
Operating conditions 0℃ - 60℃
Temperature
Room temperature Measurement range: -5℃ +65℃
Maximum temperature deviation at 20℃: 0,3℃
Features of service tool
Backlight Colour: blue
Controls Rotary and push button
Mounting See the assembly instructions provided
Quality marks and compliance with standards
4 EMC: 2004/108/EC, 55014
4 Emission EN61000-6-3
4 Immunity: EN61000-6-2
4 Drop test: IEC 68-2-32
4 RoHs Compliant
4 OpenTherm V3.0 Smartpower
Protection classification IP20
Service tool 4. Technical specifications
280113 - 7603161-01
8
