DEEP SEA ELECTRONICS DSEGenset DSE6110 MKIII User Manual

Specification
Page 19 of 148
057-289 ISSUE: 1
2.8.3.2 ANALOGUE INPUT B & C
Description
Specification
Analogue Input B Type
Flexible: Configured for Temperature Sensor in the DSE default
configuration.
Flexible Options: Not used, Digital Input, Flexible Analogue, Fuel
Sensor and Temprature Sensor
Analogue Input C Type
Flexible: Configured for Fuel Sensor in the DSE default
configuration.
Not used, Digital Input, Flexible Analogue, Fuel Sensor and
Temprature Sensor
Flexible Input Selection
Pressure Sensor, Percentage Sensor or Temperature Sensor
Flexible Measured Quantity
Resistive only
Resistive Configuration
Description
Specification
Measurement Type
Resistance measurement by measuring voltage across sensor with
a fixed current applied
Arrangement
Differential resistance measurement input
Measurement Current
13 mA ±10 %
Full Scale
3k
Over Range / Fail
5k
Resolution
±1 % of full scale
Accuracy
±2 % of full scale resistance excluding sensor error
Max Common Mode Voltage
±2 V
Display Range
Configurable by PC Software

DEEP SEA ELECTRONICS DSEGenset DSE6110 MKIII Specifications

General

Brand	DEEP SEA ELECTRONICS
Model	DSEGenset DSE6110 MKIII
Category	Control Unit
Language	English
