5.4 TEST MODE
NOTE: If a digital input configured to Panel Lock is active, changing module modes is not
possible. Viewing the instruments and event logs is NOT affected by Panel Lock.
Test Mode is activated by pressing the Test Mode button.
The LED above the Test Mode button illuminates to indicate Test Mode operations.
In Test Mode , the set does not start automatically.
To begin the starting sequence, press the Start button.
5.4.1 STARTING SEQUENCE
NOTE: There is no Start Delay in this mode of operation.
NOTE: If the unit has been configured for CAN, compatible ECU’s receives the start
command via CAN.
NOTE: For further details of module configuration, refer to DSE Publication: 057-290
DSE6110 MKIII & DSE6120 MKIII Configuration Software Manual.
The fuel relay is energised and the engine is cranked.
If the engine fails to fire during this cranking attempt then the starter motor is disengaged for the crank
rest duration after which the next start attempt is made. Should this sequence continue beyond the set
number of attempts, the start sequence is terminated and the display shows Fail to Start.
The starter motor is disengaged when the engine fires. Speed detection is factory configured to be
derived from the AC alternator output frequency, but can additionally be measured from a Magnetic
Pickup mounted on the flywheel or from the CANbus link to the engine ECU depending on module
configuration.
Additionally, rising oil pressure can be used to disconnect the starter motor (but cannot detect
underspeed or overspeed).
After the starter motor has disengaged, the Safety On Delay timer activates, allowing Oil Pressure,
High Engine Temperature, Under-speed, Charge Fail and any delayed Auxiliary fault inputs to
stabilise without triggering the fault.
