After locating the unit:
• Lock the wheels of the carriage
unlock
lock
4.4 Connecting the water supply (PH15A only)
The water supply has to be connected to the unit by a qualified specialist according to the illustration
below. The installation data has to be maintained.
Important! The local regulations regarding the connection of units to drinking water systems must
be observed.
Drinking water without additives:
– Admissible water pressure: 0.5...6.0 bar
– Admissible water temperature: 5...40 °C
Plug-in coupling ø 10 mm
Filter valve (accessory “Z261”)
• Completely unwind the mains cable (at the point of the delivery the mains cable is winded up in
the unit) and take it out of the unit as shown below.
Water pipe ø 10/6 mm
with R 3/4" connector
ø 10/6 mm
