9 Unit specifications
Dimensions (B x H x T) 730 x 610 x 370 mm
Weight (empty) 25 kg
Water tank capacity 20 l
Mains voltage
220…240 VAC/50…60 Hz or 90…110 VAC/50…60 Hz
Power consumption max. 72 Watt
Capacity levels
1)
1 2 3 4
Air circulation rate 155 mm
3
/h 195 mm
3
/h 280 mm
3
/h 340 mm
3
/h
Humidification capacity
(at 25 °C and 20 %rh)
0.8 l/hl/h 1.1 l/hl/h 1.5 l/hl/h 1.7 l/hl/h
Humidification capacity
(at 23 °C and 45 %rh)
0.6 l/hl/h 0.8 l/hl/h 1.0 l/hl/h 1.3 l/hl/h
For rooms up to a max. of
280 mm
3
380 mm
3
510 mm
3
580 mm
3
Sound pressure level
(according DIN 45635, part 1)
32 dBAdBA 37 dBAdBA 45 dBAdBA 50 dBAdBA
Admissible ambient temperature
5…40 °C
Admissible ambient humidity 0…85 %rh non condensing
Unit version PH15A
– Water supply connector plug-in coupling ø10 mm
– Admissible water pressure
0.5…6.0 bar
– Admissible water temperature 5…40 °C
Certificates VDE, CE, GS, GOST
1)
The perfomance data are based on a unit with basic equipment for humidifier operation
