Page 12
When installing the hob onto a
cabinet, a shelf must be installed
in order to separate the cabinet
from the hob as illustrated in the
above figure. This is not required
when installing onto a built-in
oven.
1 Minimum of 30 mm
If the oven is below:
If it is possible to touch the bottom of the
product if it is installed onto a drawer, then
this section must be covered with a wooden
plate.
Final check
1. Connect the power cable and switch on
the product's fuse.
2. Check the functions.
Making connections to different
holes is not a good practice in
terms of safety since it can
damage the gas and electrical
system.
Rear view (connection holes)
