Turning oī the Booster funcƟon:
Touch " " key until temperature level
decreases "0" to disable the Booster
function earlier.
If "9" will be selected as temperature level
that will be activated after Booster period
and no other lower level is selected, then
flashing of the screen will cease in 10
seconds. Booster is now deactivated.
Turn oī the hob.
If you press main key " " for longer than 2
seconds, the hob will turn off and return to
Standby mode.
If there is residual temperature that can be
used after the hob is turned off, this will be
indicated with " " symbol that appears on
the relevant cooking zone display
continuously.
Turning oī cooking zones individually:
A cooking zone can be turned off in 3
different ways:
1. By touching " " and " " keys
simultaneously.
2. By decreasing the temperature level to "0"
with " " key.
3. By using the Ɵmer funcƟon (if any) for the
relevant cooking zone
1.Touching " " and " " keys simultaneously
Select the desired cooking zone with
cooking zone selection key" ". Decimal
point appears on " " cooking zone display.
Touch " " and " " keys simultaneously to
turn off the cooking zone.
2. Decreasing the temperature level of the
desired cooking zone to "0" with " " key
Furthermore, cooking zone can also be
turned off by decreasing the temperature
level to "0".
3. Using the Ɵmer oī funcƟon (if any) for the
relevant cooking zone
When the Ɵme is over, the Ɵmer will turn oī the
cooking zone assigned to it. "0" and "00" will
appear
on all displays. Dual/triplet cooking zone and
the LEDs connected to the timer will be
deactivated. Furthermore, when the time is
over, an audible alarm will sound. Touch any
key on the touch control panel to silence the
audible alarm.
Turning on Dual/Triplet cooking zones**
Turning on the dual cooking zone:
Select the desired cooking zone equipped
with dual zone. Decimal point of the relevant
cooking zone must start to flash.
Set the temperature level to a value between
1 and 9 and touch " " key to activate the
dual zone of the cooking zone.
" " LED of the relevant dual zone will also
flash continuously. " " Status of the dual
cooking zone will change when you touch
the key for a second time: dual cooking zone
will switch between on and off status.
Expansion zone will only be activated if the
main zone of the cooking zone is set to a
temperature level between "1" and "9".
Turning on the triplet cooking zone:
Select the desired cooking zone equipped
with triplet zone. Decimal point of the
relevant cooking zone must start to flash.
Set the temperature level to a value between
1 and 9 and touch " " key to activate the
dual zone of the cooking zone.
" " LED of the relevant dual zone will also
light up continuously. If you touch " " key
again, " " LED of the triplet zone flashes
and triplet cooking zone is activated.
When you touch " " key once again
triplet zone of the cooking zone turns off
again. Above operation will always
change the status of the double/triplet
cooking zones.
Enabling the double and triplet zones by
touching the " " key of the selected
cooking zone.
Keylock * (in models with clock)
Touch the " " key for longer than 2 seconds to
lock the touch control. OperaƟon will be
conÞrmed with an audible signal.
