Interfaces
Ethernet (1x RJ45)
Query and configuration by ext. controllers (Modbus TCP, Slave),
cloud connection, communication with internal web server
Digital Inputs (3 x)
Recording digital signals
Nominal voltage 24 VDC, max. 30 VDC; high > 8.5 V; low < 7.35 V
Digital Outputs (2 x)
Output of a digital signal via a potential-free contact
(max. 24 VDC, max. 0.5 A, max. 0.25 W)
User interface
Push buttons (2 x) Control during operation
LEDs (2 x RGB) Display of different states
Standards
Safety (MSRL)
EN 61010-1: 2010 + Cor. 2011
EN 61010-2-030: 2010 + Cor. 2011
EMC (MSRL, industry, power plants)
EN 61326-1: 2013
EN 61000-6-5: 2015 + AC: 2018
Power quality (devices/features)
EN 62586-1: 2017
EN 61000-4-30: 2015
EN 50160: 2010 + Cor. 2010 + A1: 2015
Power frequency overvoltage / POP EN 50550: 2011 + AC: 2012 + A1: 2014
12. Technical data
