12. Technical data
Device general DRC SD 1 1 (Part No. 910 920) DRC SD 2 1 (Part No. 910 921)
Dimension B x H x T 90 (5 DIN modules) x 90 x 65 mm
Weight 400 g (500 g incl. packaging) 335 g (435 g incl. packaging)
Housing - material PA 12, grey
Housing - impact resistance IK 06
Installation location control cabinet
Mounting type DIN rail in main or sub-distribution, operation with panel cover
Connection supply/mains voltage measurement Busbar 2-pol./4-pol., solid wire 2-pol./4-pol.
Protection class IP20
Possible combinations
With SPD (product family), directly with busbar DEHNventil, DEHNshield, DEHNguard, DEHNbloc modular
With SPD (product family), freely wired DEHNvenCI, DEHNbloc Maxi, DEHNrail
