Split core current sensors, DRC SD SCS 100 (Part No. 910 936)
Measuring range 0 - 100 A (120 A max.), 50 Hz
Bandwidth 1.5 kHz
Accuracy class classe 1 according to IEC 61869-2
Ring diameter inside 16 mm
Dimension (W x D x H) 40.8 x 33.2 x 56.1 mm
Connection cable length 1 m
Attachment to the conductor to be measured with 2 cable ties
Weight 120 g
Safety/insulation, touchability of sensors 300 V CAT III
Safety/insulation, to the live conductor 300 V CAT III
Current sensors – Rogowski coil, divisible, flexible, DRC SD RCS 1000 (Part No. 910 937)
Measuring range 0 - 1000 A (2000 A max.), 50 Hz
Bandwidth 50 kHz
Ring diameter inside 150 mm
Dimension Ø 10 mm
Connection cable length 3 m (alternative 1 m)
Weight 250 g
Safety/insulation, touchability of sensors 300 V CAT III
Safety/insulation, to the live conductor 1000 V CAT III or 600 V CAT IV
12. Technical data
