12. Technical data
Impulse current measurement input for designated, external impulse current sensors*
Number 1
Cross-sectional area
0.08 - 2.5 mm² solid-wire
0.25 -1.5 mm² with ferrule
Connection type push-in
Measuring range 0 … 100 kA
Voltage magnitude resolution 100 A
Sampling rate 1 µs
Waveform 8/20 - 10/350 µs
Recording length max. 500 ms
Impulse values (calculated) Ipeak, Qges, Tr, Tw, category duration
Trigger threshold voltage level parameterizable via internal web server or via the cloud
* Variant with impulse current measurement expected to be available from Q4 - 2021
