12. Technical data
Impulse current sensor – DRC SD ICS 100 (Part No. 910 935)*
Recording range Ipeak 50 kA, waveform 8/20 - 10/350 µs
Bandwidth 50 kHz
Attachment to the conductor to be measured with 2 cable ties (included)
Dimensions (W x D x H) 23 x 30 x 75 mm
Connecting cable length 3 m (incl. fastening and kink protection)
Weight 25 g
Safety/insulation, touchability of sensors 300 V CAT III
* Variant with impulse current measurement expected to be available from Q4 - 2021
Mounting may only be carried out on insulated, non-hazardously active conductors.
