12. Technical data
Digital outputs (2 x)
Type PhotoMOS relay, bidirectional
Voltage max. 30 V
Current max. 500 mA
Power max. 500 mW
Switch-on resistance max. 150 mΩ
Polarity arbitrary
Isolation: connections to voltage measurement inputs 300 V CAT III
Isolation: connections to other digital outputs galvanically isolated
Isolation: connections to external DC supply 100 V
Digital inputs (3 x)
Type multifunctional
Voltage nominal voltage 24 VDC, max. 30 VDC; high > 8.5 V; low < 7.35 V
Current consumption max. 10 mA
Polarity arbitrary
Isolation: connections to voltage measurement inputs 300 V CAT III
Isolation: connections to other digital outputs galvanically isolated
Isolation: connections to external DC supply 100 V
