Deif AGC-4 Mk II Quick Start Guide

Term. Function Description
71 NO
Relay output for AVR. Lower voltage.
72 Com.
NOTE Connect PWM - to the engine battery negative and PWM + to the engine control system S-SPD (speed) input
(called RATED SPEED on the ADEM controller and PRIMARY THROTTLE on the PEEC controller).
1.6 Option EF6
Option EF6 is a hardware option: A PCB installed in slot #4. The PCB replaces the standard relay PCB in slot #4. The PWM
(Pulse Width Modulated) speed output is intended for Caterpillar
®
electronic engine control systems ADEM and PEEC.
Term.
Function Description
65 Not used
66 Not used
67 0
Speed governor, AVR or transducer output 68
68 ±25 mA
69 PWM -
PWM speed governor signal
70 PWM +
71 0
Speed governor, AVR or transducer output 72
72 ±25 mA
NOTE Connect PWM - to the engine battery negative and PWM + to the engine control system S-SPD (speed) input
(called RATED SPEED on the ADEM controller and PRIMARY THROTTLE on the PEEC controller).
1.7 Warnings, legal information and safety
1.7.1 Warnings and notes
Throughout this document, a number of warnings and notes with helpful user information will be presented. To ensure that
these are noticed, they will be highlighted as follows in order to separate them from the general text.
Warnings
DANGER!
This shows dangerous situations.
If the guidelines are not followed, these situations will result in death, serious personal injury, and equipment
damage or destruction.
Notes
NOTE
Notes provide general information, which will be helpful for the reader to bear in mind.
1.7.2 Legal information and disclaimer
DEIF takes no responsibility for installation or operation of the generator set. If there is any doubt about how to install or
operate the engine/generator controlled by the Multi-line 2 unit, the company responsible for the installation or the
operation of the set must be contacted.
NOTE
The Multi-line 2 unit is not to be opened by unauthorised personnel. If opened anyway, the warranty will be lost.
Options E F AGC-4 Mk II 4189341277C EN Page 4 of 10
