MTR-3 Installation Instructions
DEIF A/S Page 34 of 51
Active Power Total (Pt)
30253
7
302538
2536
2537
04
T_float
Reactive Power Phase L1 (Q1)
30253
9
302540
2538
2539
04
T_float
Reactive Power Phase L2 (Q2)
30254
1
302542
2540
2541
04
T_float
Reactive Power Phase L3 (Q3)
30254
3
302544
2542
2543
04
T_float
Reactive Power Total (Qt)
30254
5
302546
2544
2545
04
T_float
Apparent Power Phase L1 (S1)
30254
7
302548
2546
2547
04
T_float
Apparent Power Phase L2 (S2)
30254
9
302550
2548
2549
04
T_float
Apparent Power Phase L3 (S3)
30255
1
302552
2550
2551
04
T_float
Apparent Power Total (St)
30255
3
302554
2552
2553
04
T_float
Power Factor Phase 1 (PF1)
30255
5
302556
2554
2555
04
T_float
Power Factor Phase 2 (PF2)
30255
7
302558
2556
2557
04
T_float
Power Factor Phase 3 (PF3)
30255
9
302560
2558
2559
04
T_float
Power Factor Total (PFt)
30256
1
302562
2560
2561
04
T_float
CAP/IND P. F. Phase 1 (PF1)
30256
3
302564
2562
2563
04
T_float
CAP/IND P. F. Phase 2 (PF2)
30256
5
302566
2564
2565
04
T_float
CAP/IND P. F. Phase 3 (PF3)
30256
7
302568
2566
2567
04
T_float
CAP/IND P. F. Total (PFt)
30256
9
302570
2568
2569
04
T_float
φ1 (angle between U1 and I1)
30257
1
302572
2570
2571
04
T_float
φ2 (angle between U2 and I2)
30257
3
302574
2572
2573
04
T_float
φ3 (angle between U3 and I3)
30257
5
302576
2574
2575
04
T_float
Power Angle Total atan2(Pt,Qt))
30257
7
302578
2576
2577
04
T_float
MEASUREMENTS (IEEE 754) (VERSION 1)
Parameter
PLC
Modbus reading
Address
Adress
Funktion
Type
Start
End
Start
End
φ12 (angle between U1 and U2)
30257
9
302580
2578
2579
04
T_float
φ23 (angle between U2 and U3)
30258
1
302582
2580
2581
04
T_float
φ31 (angle between U3 and U1)
30258
3
302584
2582
2583
04
T_float
Frequency
30258
5
302586
2584
2585
04
T_float
