Deif MTR-3 - Register table for Settings (VERSION 2); System commands; General settings

Register table for Settings (VERSION 2)
Parameter
PLC
Modbus reading
Values/dependences
Address
Adress
Type Ind
Start
End
Start
End
SYSTEM COMMANDS
User Password (L1, L2)
400001
400002
0
1
T_Str4
A...Z
Password to attempt user access
level upgrade
Factory Password (FAC)
400003
400005
2
4
T_Str6
A...Z
Password to attempt factory access
level upgrade
Level 1 - User password
400006
400007
5
6
T_Str4
A...Z
Level 2 - User password
400008
400009
7
8
T_Str4
A...Z
Active Access Level
400010
9
T1
0
Full protection
1
Access up to level 1 user password
2
Access up to level 2 user password
3
Access up to level 2 (backup pass.)
4
Factory access level
Manual password activation
400011
10
T1
1
Lock instrument
Operator Command Register
400012
11
T1
1
Save Settings
2
Abort Settings
3
Restart Instrument
Reset command register 1
400013
12
T1
Bit-0
Reset counter 1
Bit-1
Reset counter 2
Bit-2
Reset counter 3
Bit-3
Reset counter 4
Bit-10
Reset last period MD
Bit-11
Reset MD values
Reset command register 2
400014
13
T1
Bit-0
Reset alarm output relay 1
Bit-1
Reset alarm output relay 2
Bit-2
Reset alarm output relay 3
Bit-3
Reset alarm output relay 4
Reserved
400015
400099
14
98
GENERAL SETTINGS
Modbus register tables for measurements
400101
100
T1
0
Version 1 - MTR-3
1
Version 2 - compatible with MTR-2
Description
400102
400120
101
119
T-
Str40
Location
400123
400140
122
139
T-
Str40
Password activation
400142
141
Reserved
Password lock time
400143
142
T1
Minutes, 0 = No lock
Conection Mode
400144
143
T1
0
No mode
1
1b - Single Phase
2
3b - 3 phase 3 wire balanced
3
4b - 3 phase 4 wire balanced
4
3u - 3 phase 3 wire unbalanced
5
4u - 3 phase 4 wire unbalanced
CT Secundary
400145
144
T4
mA
CT Primary
400146
145
T4
A/10
VT Secundary
400147
146
T4
mV
VT Primary
400148
147
T4
V/10
Current input range (%)
400149
148
T16
10000 for 100%
Voltage input range (%)
400150
149
T16
10000 for 100%
Frequency nominal value
400151
150
T1
Hz
CT Connection
400152
151
T1
Bit-0
Disable display "Wrong connection"
Bit-1
Reverse Energy flow direction
Bit-2
Reverse CT connection
MD Time constant
400153
152
T1
minutes (0=disabled)
