6. Appendix A - Pointer position examples
The pointer positions of the indicators at different inputs depend on the configuration of the indicator. The pointer positions
in the example are for an analogue pitch indicator with a range of 4 to 20 mA. The pointer rotates in a clockwise direction
when the indicator receives a positive input.
Table 6.1 Pointer positions based on input
Minimum value (4 mA) Electrical middle (12 mA) Maximum value (20 mA)
Table 6.2 Pointer error positions
Minimum Electrical middle + 180° Maximum
Installation and commissioning guide 4189350024O EN Page 35 of 39
