proxSafe flexx
3.9.2 Connect PC with proxSafe terminal via backplane PCB
The second option for operating the flexx system using the proxSafe terminal without
network connection is to directly connect the PC to the backplane PCB. For this connect
the SNG 3 as follows:
1.
Set both dip switches on the adapter to
position “ON”.
2.
Connect to SNG 3 as follows:
b) USB connector to PC
d) “To PC” on backplane (green 4 pin)
