1. Technical Data
Housing
dimensions (mm): 465 x 609 x 210 (6U, “Small”), for up to 32 proxCylinders
698 x 621 x 210 (12U, “Medium”), for up to 64 proxCylinders
1396 x 621 x 210 (24U, “Large”), for up to 128 proxCylinders
Housing material: sheet steel, powder coated
Weight: approx. 12 kg (Housing “Small”)
approx. 20 kg (Housing “Medium”)
approx. 60 kg (Housing “Large”)
keyPanel options: 3U with 16 proxCylinders (480 mm x 132,5 mm)
6U with 16 proxCylinders (480 mm x 265,5 mm)
Door options: steel door,
steel door with inserted window pane
(window=polycarbonate, makrolon
®
),
without door
Power consumption: 13.8 V/DC, max. 2.0 A;
back-up battery in case of power failure (optional)
Outputs: door strike
output 1-4: potential-free contacts
Terminal Interface: RS485/deBUS
Ethernet adapter (optional)
