Table 42 U- and D-Series 10 GB public switch network cabling for all Arista models (continued)
Chassis / node /
10GB adapter port
Switch port / label
(rabbit, SW1)
Switch port / label
(hare, SW2)
Label color
1 / Node 4 P02 (Left) 10G SW2 P12
2 / Node 5 P01
(Right)
10G SW1 P13 Brown
2 / Node 5 P02 (Left) 10G SW2 P13
2 / Node 6 P01
(Right)
10G SW1 P14 Light Blue
2 / Node 6 P02 (Left) 10G SW2 P14
2 / Node 7 P01
(Right)
10G SW1 P15 Purple
2 / Node 7 P02 (Left) 10G SW2 P15
2 / Node 8 P01
(Right)
10G SW1 P16 Magenta
2 / Node 8 P02 (Left) 10G SW2 P16
Note
1.5m (U-Series) or 3m (C-Series) Twinax network cables are provided for 10GB.
Table 43 U- and D-Series 10 GB public switch MLAG cabling for all Arista models
Connection Connection 10 GB
SW1 (rabbit)
Port number 10
GB SW2 (hare)
Port number
labels
MLAG cables (71xx 10
GB switches)
23 23 10G SW1 P23
10G SW2 P23
24 24 10G SW1 P24
10G SW2 P25
MLAG cables
(7050x10 GB
switches)
45 45 10G SW1 P45
10G SW2 P45
46 46 10G SW1 P46
10G SW2 P46
47 47 10G SW1 P47
10G SW2 P47
48 48 10G SW1 P48
10G SW2 P48
Note
1m Twinax network cables are provided to cable 10 GB switch to switch MLAG.
Network Cabling
Network cabling 101
