2. RMM: A dedicated port for hardware monitoring (per node)
3. SAS to DAE. Used on U- and D-Series servers only. U-Series Gen1 has a single
port. U-Series Gen2 hardware has two ports. The D-Series has one high density
SAS cable with one connector.
4. 10 GbE SW2 (
hare
): The left 10 GbE data port of each node is connected to one of
the data ports on the 10 GbE (SW2) switch
5. 10 GbE SW1 (
rabbit
): The right 10 GbE data port of each node is connected to one
of the data ports on the 10 GbE (SW1) switch
Rack and node host names
Lists the default rack and node host names for an ECS appliance.
Default rack IDs and color names are assigned in installation order as shown below:
Table 17 Rack ID 1 to 50
Rack
ID
Rack color Rack
ID
Rack color Rack
ID
Rack color
1 red 18 carmine 35 cornsilk
2 green 19 auburn 36 ochre
3 blue 20 bronze 37 lavender
4 yellow 21 apricot 38 ginger
5 magenta 22 jasmine 39 ivory
6 cyan 23 army 40 carnelian
7 azure 24 copper 41 taupe
8 violet 25 amaranth 42 navy
9 rose 26 mint 43 indigo
10 orange 27 cobalt 44 veronica
11 chartreuse 28 fern 45 citron
12 pink 29 sienna 46 sand
13 brown 30 mantis 47 russet
14 white 31 denim 48 brick
15 gray 32 aquamarine 49 avocado
16 beige 33 baby 50 bubblegum
17 silver 34 eggplant
Nodes are assigned node names based on their order within the server chassis and
within the rack itself. The following table lists the default node names.
Table 18
Default node names
Node Node name Node Node name Node Node name
1 provo 9 boston 17 memphis
Servers
30 D- and U-Series Hardware Guide
