Dell EMC PowerSwitch N3224F-ON User Manual

Table 14. Power consumption parameters (continued)
Parameter Specifications
Maximum steady current consumption
● 7 A@110 VAC
● 3.5 A@220 VAC
Total PoE budget
NOTE: To support a full-load PoE power budget, you
must have external power adapters for the N3208PX-ON
switch. For the N3224PX-ON, N3248P-ON, and
N3248PXE-ON switches, use the EPS for full-load PoE
redundancy.
● N3208PX-ON: 720 W
● N3224P-ON: 720 W
● N3224PX-ON: 2160 W
● N3248P-ON: 1440 W
● N3248PXE-ON: 4320 W
PoE output per port
● N3208PX-ON: 4x1G Base-T Ports with 4 ports of 802.3bt
Type-4 (90W) PoE, + 4x5GBase-T Ports with 4 ports of
802.3bt Type-4 (90W) PoE
● N3224P-ON: 24x1G Base-T Ports with 802.3at Type-2
(30W) PoE
● N3224PX-ON: 24x10GBase-T Ports with 802.3bt Type-4
(90W) PoE
● N3248P-ON: 48x1G Base-T Ports with 802.3at Type-2
(30W) PoE
● N3248PXE-ON: 48x10GBase-T Ports with 802.3bt Type-4
(90W) PoE
PoE load condition—high-line AC input N3208PX-ON:
● Max PoE power 193 - 793 W (170-264 Vac)—No EPS
N3224PX-ON:
● Max PoE power 1050, 1600, 2000 W (180-264 Vac)—
Single EPS
● Max PoE power up to 2400 W (180-264 Vac)—Three-slot
EPS
N3224P-ON:
● Max PoE power 1050, 1600, 1750 W (180-264 Vac)—No
EPS
N3248P-ON:
● Max PoE power 1050, 1600, 1750 W (180-264 Vac)—
Single EPS
● Max PoE power up to 1440 W (180-264 Vac)—Three-slot
EPS
N3248PXE-ON:
● Max PoE power 1050, 1600, 2000 W (180-264 Vac)—
Single EPS
● Max PoE power up to 4800 W (180-264 Vac)—Three-slot
EPS
PoE load condition—low-line AC input
N3208PX-ON:
● Max PoE power 193 - 793 W (90-132 Vac)—No EPS
N3224PX-ON:
● Max PoE power 1050, 1600, 2000 W (90-140 Vac)—Single
EPS
● Max PoE power up to 2400 W (90-140 Vac)—Three-slot
EPS
N3224P-ON:
Specifications 79
