Table 14. Power consumption parameters (continued)
Parameter Specifications
● Max PoE power 1050, 1600, 2000 W (90-140 Vac)—No
EPS
● Max PoE power up to 1440 W (90-140 Vac)—Three-slot
EPS
N3248P-ON:
● Max PoE power 1050, 1600, 2000 W (90-140 Vac)—Single
EPS
● Max PoE power up to 1440 W (90-140 Vac)—Three-slot
EPS
N3248PXE-ON:
● Max PoE power 1050, 1600, 2000 W (90-140 Vac)—Single
EPS
● Max PoE power up to 4800 W (90-140 Vac)—Three-slot
EPS
Table 15. AC power requirements
Parameter Specifications
Power supply
● N3208PX-ON: 100–240 VAC 50/60 Hz
● N3224T-ON: 100–240 VAC 50/60 Hz
● N3224F-ON: 100–240 VAC 50/60 Hz
● N3224P-ON: 100–240 VAC 50/60 Hz
● N3224PX-ON: 100–240 VAC 50/60 Hz
● N3248TE-ON: 100–240 VAC 50/60 Hz
● N3248P-ON: 100–240 VAC 50/60 Hz
● N3248X-ON: 100–240 VAC 50/60 Hz
● N3248PXE-ON: 100–240 VAC 50/60 Hz
Maximum current draw per system
● N3208PX-ON: 7A@110VAC and 3.5A@220VAC
● N3224T-ON: 7A@110VAC and 3.5A@220VAC
● N3224F-ON: 7A@110VAC and 3.5A@220VAC
● N3224P-ON: 7A@110VAC and 3.5A@220VAC
● N3224PX-ON: 17A@110VAC and 3.5A@220VAC
● N3248TE-ON: 7A@110VAC and 3.5A@220VAC
● N3248P-ON: 7A@110VAC and 3.5A@220VAC
● N3248X-ON: 7A@110VAC and 3.5A@220VAC
● N3248PXE-ON: 7A@110VAC and 3.5A@220VAC
Maximum power consumption without PoE
● N3208PX-ON: 107 W @ 54 VDC
● N3224T-ON: 201 W @ 54 VDC
● N3224F-ON: 224 W @ 54 VDC
● N3224P-ON: 224 W @ 54 VDC
● N3224PX-ON: 340 W @ 54 VDC
● N3248TE-ON: 212 W @ 54 VDC
● N3248P-ON: 237 W @ 54 VDC
● N3248X-ON: 480 W @ 54 VDC
● N3248PXE-ON: 554 W @ 54 VDC
Table 16. DC power requirements
Parameter Specifications
Minimum and maximum input voltage –40 VDC to -60 VDC
80 Specifications
