Dell 2007FP User Manual

9/20/12
Documentation
5/10
support.dell.com/support/edocs/monitors/2007FP/en/ug/about.htm#Front View
Luminance output 300 cd/m ²(typ)
Contrast ratio 800:1 (typ)
Faceplate coating Antiglare with hard-coating 3H
Backlight CCFL (6) edgelight system
Response Time 16ms typical
Resolution
Horizontal scan range 30 kHz to 81 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz, exception 1600 x 1200 at 60 Hz only
Optimal preset resolution 1600 x 1200 at 60 Hz
Highest preset resolution 1600 x 1200 at 60 Hz
Video Supported Modes
Video display capabilities (DVI playback) 480p/576p/720p
Video display capabilities (Composite playback) NTSC/PAL
Video display capabilities (S-Video playback) NTSC/PAL
Preset Display Modes
Dell™ guarantees image size and centering for all preset modes listed in the following table.
Display Mode Horizontal Frequency
(kHz)
Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity
(Horizontal/Vertical)
VGA, 720 x 400 31.5 70.1 28.3 -/+
VGA, 640 x 480 31.5 59.9 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.3 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1152 x 864 67.5 75.0 108.0 +/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1600 x 1200 75.0 60.0 162.0 +/+
Electrical
Video input signals Analog RGB, 0.7 Volts +/-5%, 75 ohm input impedance
Digital DVI-D TMDS, 600mV for each differential line, 50 ohm
input impedance
S-video, Y input 1 volt(p-p), C input 0.286 volt(p-p), 75 ohm input
impedance
Composite, 1 volt(p-p), 75 ohm input impedance
Synchronization input signals separate horizontal and vertical,
3.3V CMOS or 5V TTL level, positive or negative sync.
SOG (Sync on green)
AC input voltage / frequency / current 100 to 240 VAC / 50 or 60 Hz + 3 Hz / 2.0A (Max.)
Inrush current 120V: 40A (Max.)
240V: 80A (Max.)
Physical Characteristics
Signal cable type D-sub: Detachable, Analog, 15pin, shipped attached to the
monitor
DVI-D: Detachable, Digital, 24pin, shipped detached from the
monitor
S-video: Not included with display
Composite: Not included with display

Dell 2007FP Specifications

General

Screen Size	20.1 inches
Resolution	1600 x 1200
Aspect Ratio	4:3
Panel Type	IPS
Brightness	300 cd/m²
Contrast Ratio	800:1
Response Time	16 ms
USB Ports	4 x USB 2.0
Color Support	16.7 million colors
VESA Mount	100 x 100 mm
Viewing Angles	178° horizontal / 178° vertical
Inputs	DVI-D, VGA
Weight	17 lbs
