Composite: Not included with display
Dimensions (with stand):
Height (fully extended in portrait mode) 547.6 mm (21.6 inches)
Height (compressed/locked in landscape mode) 367 mm (14.5 inches)
Width 445.3 mm (17.5 inches)
Depth 193.50 mm ( 7.6 inches)
Weight
Monitor (Stand and Head) 6.9 Kg (15.2 lb)
Monitor Flat panel only (VESA Mode) 5.2 Kg (11.5 lb)
Weight with packaging 9.6 Kg (21.2 lb)
Environmental
Temperature:
Operating 5° to 35°C (41° to 95°F)
Non-operating Storage: 0° to 60°C (32° to 140°F)
Shipping: -20° to 60°C(-4° to 140°F)
Humidity:
Operating 10% to 80% (non-condensing)
Non-operating Storage: 5% to 90% (non-condensing)
Shipping: 5% to 90%(non-condensing)
Altitude:
Operating 3,657.6 m (12,000 ft) max
Non-operating 12,192 m (40,000 ft) max
Thermal dissipation 256.0 BTU/hour (maximum)
187.66 BTU/hour (typical)
Power Management Modes
If you have VESA's DPMS compliance display card or softw are installed in your PC, the monitor can automatically reduce its power consumption when not
in use. This is referred to as 'Power Save Mode'*. If activity from keyboard, mouse or other input devices is detected by the computer, the monitor will
automatically "wake up". The follow ing table shows the power consumption and signaling of this automatic power saving feature:
VESA Modes Horizontal Sync Vertical Sync Video Power Indicator Power Consumption
Normal
operation
Active Active Active Green 75W (maximum)*
55W (normal)**
Active-off mode Inactive Inactive Blanked Amber Less than 2 W
Switch off - - - Off Less than 1 W (at 230 V)
* With Audio + USB
** Without Audio + USB
This monitor is ENERGY STAR®-compliant as well as TCO '99/ TCO '03 power management compatible.
* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.
Pin Assignments
VGA Connector
