Installation procedure for 2x GbE LAN uFM
module
About this task
Installation requires the removal of WiFi, as well as COM3 and COM4 ports. The four-port COM cable will be replaced with an
included dual-port COM cable.
Table 18. Expansion module packing list
Item Quantity Notes
Screw M3 x 6L 2 Torque required: 4.0 kgf.cm
Screw M3 x 4L 14 Torque required: 4.0 kgf.cm
Screw M3 x 5L 1 Torque required: 4.0 kgf.cm
Standoff H4 4 Torque required: 4.5 kgf.cm
Nut M3 4 Torque required: 4.0 kgf.cm
Screw M2.5 x 6L 2 Torque required: 3.0 kgf.cm
Cable tie 2 -
Rubber cap 2 -
Cable clip 1 -
Sheet metal I/O panel 1 -
Bracket 1 -
LAN PCBA 1 -
LAN mPCIe 1 -
Dual-port COM cable 1 -
LAN cable 2 -
Table 19. Tools needed
Tool Notes
Phillips head screwdriver Small size
Needle-nose pliers —
Nut driver 4.5 mm, 5 mm, 5.5 mm
Steps
1. Remove the eight screws from the bottom panel of the EGW-5200, as shown in the following figure, and remove the bottom
panel.
VI
Installation procedure for 2x GbE LAN uFM module 55
