22 About Your Computer
AUDIO CONNECTORS
USB CONNECTORS
IEEE 1394 CONNECTOR — Connects devices supporting IEEE 1394 high-speed transfer rates, such as some digital
video cameras.
Back View
Attach headphones or speakers to the connector.
Attach a microphone to the connector.
Connect USB devices, such as a mouse, keyboard, or printer. You can also connect
the optional floppy drive
directly to a USB connector using the optional floppy-
drive
cable.
1 AC adapter connector 3 modem connector (RJ-11) 5 video connector
2 network connector (RJ-45) 4 USB connectors (2) 6 S-video TV-out connector
1 4 532 6
