Adding and Replacing Parts 127
Internal Card With Bluetooth
®
Wireless Technology
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as a connector on the back of the computer).
NOTICE: To help prevent damage to the system board, you must remove the battery from the battery bay before
you begin working inside the computer.
If you ordered a card with Bluetooth wireless technology with your computer, it is already installed.
1
Follow the procedures in "Before You Begin" on page 109.
2
If you have not already removed the battery, do so now.
Slide and hold the battery-bay latch release on the bottom of the computer, and then remove the
battery from the bay.
3
Open the card door and remove it from the computer.
4
Pull the card out of the compartment so that you can disconnect the card from its cable and remove it
from the computer.
5
To replace the card, connect the card to the cable and then carefully insert it into the compartment.
6
Replace the card door by inserting the small center tab into the notch at the base of the compartment
and snapping the card into place.
1 card door 2 cable 3 card
1
3
2
