56 Using Multimedia
4
Plug the other end of the composite video cable into the composite video-input connector on the TV.
5
Plug the single-connector end of the audio cable into the headphone connector on the computer.
6
Plug the two RCA connectors on the other end of the audio cable in to the audio input connectors on
your TV or other audio device.
7
Turn on the TV, turn on any audio device that you connected (if applicable), and then turn on the
computer.
8
See "Enabling the Display Settings for a TV" on page 63 to ensure that the computer recognizes and
works properly with the TV.
Composite Video and S/PDIF Digital Audio
1 composite video adapter 2 composite video cable
1 S-video TV-out connector 2 composite video adapter
2
1
1 2
