Installing Blade Components 173
Independent Channel Mode (Optimizer Mode) – PowerEdge M710
In this mode, all three channels are populated with identical memory
modules. This mode permits a larger total memory capacity, but does not
support the reliability features of the other modes. To enable this mode,
select the Optimizer option on the Memory Settings screen of the System
Setup program. See "Memory Settings Screen" on page 130.
A minimal single-channel configuration of one 1 GB memory module per
processor is also supported in this mode.
Table 3-7. Examples of PowerEdge M710 Memory Configurations
Total
Physical
Memory
Memory Modules
– Number and
Type
Memory Module
Locations
Processors Memory
Mode
Available
Memory
1 GB One 1 GB
UDIMM
A1 One Independent
channel
1 GB
2 GB Two 1 GB
UDIMMs
A2, A3 One Mirroring 1 GB
2 GB Two 1 GB
UDIMMs
A2, A3 One Advanced
ECC
2 GB
2 GB Two 1 GB
UDIMMs
A1, B1 Two Independent
channel
2 GB
4 GB Two 2 GB
UDIMMs
A2, A3 One Mirroring 2 GB
4 GB Two 2 GB
UDIMMs
A2, A3 One Advanced
ECC
4 GB
4 GB Four 1 GB
UDIMMs
A2, A3, B2, B3 Two Mirroring 2 GB
4 GB Four 1 GB
UDIMMs
A2, A3, B2, B3 Two Advanced
ECC
4 GB
6 GB Six 1 GB
UDIMMs
A1, A2, A3, B1,
B2, B3
Two Independent
channel
6 GB
6 GB Three 2 GB
UDIMMs
A1, A2, A3 One Independent
channel
6 GB
8 GB Four 2 GB
UDIMMs
A2, A3, B2, B3 Two Mirroring 4 GB
