Installing Blade Components 197
Figure 3-21. Removing and Installing the Mezzanine Interface Card (M610x Only)
1 mezzanine interface card 2 cable management clip
3 card retention latch 4 mezzanine card connector (2)
5 data cable connector (2) 6 retention latch slot
1
2
3
6
5
4
