284 Installing Enclosure Components
Figure 4-11. Removing and Installing the LCD Module
2 Remove the cable cover.
3 Disconnect the ribbon cable.
4 Remove the two screws securing the LCD module to the hinges.
1 cable cover 2 LCD module
3 ribbon cable 4 hinges (2)
5 screws (2)
1
2
3
4
5
