System Board Information 317
5- Optional RAID battery
6 D1 – D4 Memory modules D1 – D4
7 - Connector for the 3.0-V coin battery
NOTE: Access requires removal of system board. See
"Removing the System Board" on page 255.
8 J_STORAGE Storage controller card connector
9 C1 – C8 Memory modules C1 – C8
10 - Hard-drive backplane connector
11 A1 – A8 Memory modules A1 – A8
12 CPU3 Processor 3 socket
13 J_RIPS_SD2 SD vFlash Card slot
14 MEZZ1_FAB_C Mezzanine card connector for Fabric C
15 MEZZ2_FAB_B Mezzanine card connector for Fabric B
16 CPU1 Processor 1 socket
17 MEZZ3_FAB_C Mezzanine card connector for Fabric C
18 MEZZ4_FAB_B Mezzanine card connector for Fabric B
19 - System board retention pin
20 PSWD_EN,
NVRAM_CLR
System configuration jumpers
NOTE: Access requires removal of system board. See
"Removing the System Board" on page 255.
Table 7-8. PowerEdge M910 System Board Connectors
(continued)
Connector Description
